Teledyne 200E - First Calibration

Getting Started Model 200E Instruction Manual
3.6. First Calibration
3.6.1. Basic Calibration Procedure
The initial calibration should be carried out using the 500 ppb range, a span gas with about
400 ppb NO and with the unit set for SINGLE range, which will enable you to compare your
calibration results to the factory calibration as listed on the Final Test and Validation Data
Sheet. The following three-step procedure assumes that the instrument does not have any
of the available zero/span (Z/S) valve options installed. Chapter 7 contains instructions for
calibrating instruments with Z/S valve options, Chapter 8 for EPA protocol calibration.
Set the analog output range of the M200E:
SETUP X.X RANGE CONTROL MENU
MODE SET UNIT EXIT
Press this button to set
the analyzer for
SNGL
DUAL or IND ranges
SETUP X.X RANGE: 500.0 CONC
0 0 5 0 0 .0 ENTR EXIT
To change the value of the
reporting range span, enter the
number by pressing the key under
each digit until the expected value
appears.
Press this button to select the
concentration units of measure:
PPB, PPM, UGM, MGM
EXIT ignores the new setting and
returns to the RANGE CONTROL
MENU.
ENTR accepts the new setting and
returns to the
RANGE CONTROL MENU.
SETUP X.X
CFG DAS RNGE PASS CLK MORE EXIT
SAMPLE RANGE = 500.0 PPB NOX= X.X
< TST TST > CAL SETUP
SETUP X.X RANGE: 500.0 Conc
0 0 0 5 0 .0
ENTR EXIT
Set the expected NO and NOx span gas concentration. If you supply NO gas to the
analyzer, the values for expected NO and NO
x
need to be identical.
This sequence causes the
analyzer to prompt for the
expected NO and NO
x
span concentration.
EXIT
ignores the new setting and
returns to the
CONCENTRATION
MENU
.
ENTR
accepts the new setting and
returns to the
CONCENTRATION MENU
..
M-P CAL
CONCENTRATION MENU
NOX
NO CONV EXIT
M-P CAL
NOX SPAN CONC: 400.0 Conc
0 0 0
4 0 .0 ENTR EXIT
M-P CAL
CONCENTRATION MENU
NOX
NO
CONV EXIT
M-P CAL
NO SPAN CONC: 400.0 Conc
0 0 0
4 0 .0 ENTR EXIT
M-P CAL RANGE = 500.0 PPB NO = X.X
< TST TST > ZERO
CONC
EXIT
SAMPLE RANGE = 500.0 PPB NOX= X.X
< TST TST >
CAL
SETUP
The NO
x
& NO span concentration
values automatically default to
400.0 Conc
.
To change this value to the actual
concentration of the span gas, enter
the number by pressing the key
under each digit until the expected
value appears.
26 044100102 Rev A
