Model 200E Instruction Manual APPENDIX B
APPENDIX B: Spare Parts and Expendables
NOTE
Use of replacement parts other than those supplied by Teledyne-API
may result in non-compliance with European standard EN 61010-1.
The following listings contain spare parts for individual ordering as well as recommended
stocking levels for operation of multiple analyzers to minimize downtime for any one
analyzer unit.
The expendables (chemicals, filters, O-rings etc) are not included in the spare parts listing,
neither are optional analyzer components as listed in Chapter 5.
Table B-1: M200E Individual Spare Parts List
Part Number Description Notes
000940100 CD, ORIFICE, 0.003” GREEN Flow Control Orifice, 40 cm³/min, high
concentration sample flow
000940400 CD, ORIFICE, 0.004” BLUE Flow Control Orifice, 80 cm³/min, standard
ozone flow
000940500 CD, ORIFICE, 0.007” ORANGE Flow Control Orifice, 250 cm³/min, optional
sample and/or ozone flow
000940600 CD, ORIFICE, 0.010” BROWN Flow Control Orifice, 500 cm³/min, standard
sample flow
002270000 GASKET, WINDOW Gasket for reaction cell window
002730000 CD, FILTER, 665NM Reaction cell optical glass filter
003290000 THERMISTOR, BASIC Thermistor for reaction cell. Also used in IZS
option, bypass manifold and O
2
sensor.
009070000 COOLER, T.E Thermo-electric PMT cooler
010150101 ASSY, MOLY CONVERTER WELDED
CARTRIDGE
NO
2
converter cartridge, guts only without
heater and thermocouple
011930000 CD, PMT, NOX, M200AR928 Photo multiplier tube (PMT)
013140000 ASSY, COOLER FAN, M200A 92 mm PMT cooling fan under PMT housing
014080100 ASSY, HVPS, SOX/NOX PMT socket and high voltage power supply
including LED and thermistor housing.
016290000 WINDOW, SAMPLE FILTER, 47MM Replacement glass window for sample filter
024710000 ASSY, TUBING, TU0000001, 6FT Clear FEP tubing, 1/8” OD, ~1.8 m
024720000 ASSY, TUBING, TU0000002, 6FT Black FEP tubing, 1/8” OD, ~1.8 m
024750000 ASSY, TUBING, TU0000009, 6FT Clear PVC tubing, 1/4” OD, ~1.8 m
037860000 ORING, TEFLON, RETAINING RING,
47MM
Sample filter retaining ring
040010000 ASSY, FAN REAR PANEL, E SERIES 60 mm main chassis fan on rear panel
040300100 ASSY, 115V CONFIG PLUG, M200E Power configuration plug for 115 V AC
040300200 ASSY, 230V CONFIG PLUG, M200E Power configuration plug for 230 V AC
044100120 Rev A 251
