APPENDIX B Model 200E Instruction Manual
Part Number Description Notes
040690100 PCA, E SERIES MTHRD W/MICROFITS,
AMBIENT
Analyzer Motherboard
040900000 ORIFICE HOLDER, M200E REACTION
CELL
Orifice holder only; does not include fitting, O-
rings or any orifice assembly parts
041710000 CPU, CONFIGURATION, "E" SERIES CPU board including EEPROM. Needs
043890100 disk-on-chip with software
043890100 DOC, w/SOFTWARE, M200E Disk-on-chip with all required software, needed
for 041710000 CPU board.
042580000 PCA, KEYBOARD, E-SERIES, W/V-
DETECT
Front panel keyboard and display board.
Requires separate display DS0000009
044190000 ASSY, OZONE FILTER UNIT Cartridge includes all fittings, chemical and
mounting screws
044470001 044470001 MOD, O3 FILTER
FITTING, FT294, M200E
FT 294 with pressed-in sintered filter. O
3
filter
requires two
045500100 ASSY, ORIFICE HOLDER, 4 MIL Complete assembly to replace critical orifice, O-
rings, sintered filter, spring and fitting FT10 for
the ozone supply gas. Nominal 80 cm³/min
045500300 ASSY, ORIFICE HOLDER, 10 MIL As previous, except for the sample gas.
Nominal 500 cm³/min
045500200 ASSY, ORIFICE HOLDER, 7 MIL As previous, except for the optional bypass
manifold or high ozone flow. Nominal 250
cm³/min
045500400 ASSY, ORIFICE HOLDER, 3 MIL Same as previous, 40 cm³/min flow
045500500 ASSY, ORIFICE HOLDER, no orifice Same as previous, without orifice
DS0000009 DISPLAY Vacuum fluorescence display. Mounts on
042580000 keyboard PCA.
FL0000001 FILTER, SS Filter for flow control assembly (All Versions)
FM0000004 FLOWMETER Ozone supply air flow meter
FT0000010 CONNECTOR-ORING, SS, 1/8" Fitting to cap orifice holder
FT0000190 NUT, DELRIN, 1/4-28, 1/8 TUBE Replacement nut for FT294, O
3
filter fitting
FT0000267 BURKERT FERRULE TOOL For O
3
filter assembly fittings
FT0000303 FERRULE, 1/4-28, 1/8 TUBE, FOR
FT294
Replacement ferrule for FT294, O
3
filter fitting
HE0000017 HEATER, 12W/120V (50W/240V) CE
APPROVED
Reaction cell heater cartridge. Also used in IZS
option, bypass manifold and O
2
sensor.
HW0000020 SPRING Spring for flow control assembly
HW0000036 TFE TAPE, 1/4" (48 FT/ROLL) Teflon tape for NPT threaded fittings
IC0000208 IC QUAD DARLINGTON POWER
DRIVER UDN2540B
Valve driver chip on relay board
KIT000115 OPTION, SAMPLE GAS CONDITIONER,
M200A/ E
Ozone air or sample air dryer only, without
bracket
OR0000001 ORING, 2-006VT O-ring for flow control assemblies (2 per assy)
OR0000002 ORING, 2-023V O-ring seals ends of reaction cell (2 required)
OR0000034 ORING, 2-011V FT10 O-ring for FT 10 (one per fitting)
OR0000039 ORING, 2-012V O-ring for orifice holder (one per fitting)
252 044100120 Rev A
