Teledyne 200E - M200 E Recommended Spare Part Stocking Levels

Model 200E Instruction Manual APPENDIX B
Part Number Description Notes
OR0000044 ORING, 2-125V O-ring seals reaction cell to PMT housing
PS0000029 EOS SWITCHING PS, +5V, +/-15V,
40W
5 V and ±15V power supply for all electronics
PS0000031 EOS SWITCHING PS, 12V, 60W 12 V Power supply for PMT cooler and valves
RL0000015 RELAY, DPDT, GORDOS PREFERRED Power relays for heater circuits. M200E needs
two, IZS, bypass manifold and O
2
sensor
options one more each
SW0000025 PWR SWITCH/CIRCUIT BREAKER, VDE
CE 6.75A
Power switch on front panel
VA0000007 VALVE, 3-WAY SS, 12VDC Valve for NO/NO
X
and AutoZero as well as both
IZS option valves
WR0000008 POWER CORD, 10A Main power cord
Table B-2: M200E Recommended Spare Part Stocking Levels
PART NO. DESCRIPTION Number of analyzers
1 2- 5 6-10 11-20 21-30
010150100 Subassy, Moly Con Cartridge 1 1
011310000
1
Assy, Dryer, NOX 1 2 3 4
011930000 PMT, NOX 1 1
014080100 Assy, HVPS, SOX/NOX 1 1
014610000 Replacement Cooler Assembly 1 2 3 3
039550200 PCA, Relay Card, M100E/M200E, w/Relays 1 1 2
040010000 Assy, Fan Rear Panel, E Series 1 1 2 4 4
040030800 PCA, Press Sensor (2X), Flow, E Series 1 2 3
040420200 Assy, O3 Brick, M200EH, High Output 1
040690100 E Series Mother Board 1 2
041710000 CPU, Configuration "E" Series 1 1
041800200 PCA, PMT Preamp, M200E/EH 1 1
042580000 PCA, Keyboard, E- Series, W/V-Detect 1 1
044470001 1/4" NPT TO 1/4-28 FEMALE ADAPTER U500 1 1 2 4
044610000 Assy, Valves, Moly Hicon, M200E/EH 1 2
045500100 4 Mil Orifice Holder (O
3
stream) 1 1 2 2 4
045500300 10 Mil Orifice Holder (sample stream) 1 1 2 2 4
DS0000009 Display 1 1
FM0000004 Flow meter for O
3
flow 1 2 3
FT0000267 BURKERT FERRULE TOOL for 044470001 fitting. 1 2 4 8 16
FT0000303 FERRULE, 1/4-28, 1/8 TUBE, FOR 044470001 2 2 4 6 10
HE0000017 Heater, 12V, 120W(50V, 240W) CE approved 1 1 2 2 3
OR0000034 O-Ring, 2-011V 2 5 10
OR0000044 O-Ring, 2-125V 2 5 10
044100120 Rev A 253
