Model 200E Instruction Manual Optional Hardware and Software
Table 5-1: IZS or Z/S Valve States
Mode Valve Condition
Valve Port Connection
NO = normally open port
NC = normally closed port
COM = common port
Sample/Cal Open to sample gas inlet NO ! COM SAMPLE
Zero/Span Open to zero air inlet NO ! COM
Sample/Cal Open to zero/span inlet (activated) NC ! COM ZERO CAL
Zero/Span Open to zero air inlet NO ! COM
Sample/Cal Open to zero/span inlet (activated) NC ! COM SPAN CAL
Zero/Span Open to span gas inlet / IZS gas (activated) NC ! COM
The state of the IZS valves can also be controlled:
Manually from the analyzer’s front panel by using the SIGNAL I/O controls located
under the DIAG Menu (Section 6.8.1),
By activating the instrument’s AutoCal feature (Section 7.8),
Remotely by using the external digital control inputs (Section 6.9), or
Remotely through the RS-232/485 serial I/O ports (Section 6.9.10).
Sources of zero and span gas flow must be capable of supplying at least 600 cm
3
/min as
the analyzer draws about 500±50 cm³/min into the instrument. Both supply lines should be
vented outside of the analyzer’s enclosure. In order to prevent back-diffusion and pressure
drop effects, these vent lines should be between 2 and 10 meters in length.
5.5.2. Internal Zero/Span (IZS) (Option 51)
The M200E can be equipped with an internal zero air and span gas generator system (IZS).
This option includes a heated enclosure for a NO
2
permeation tube, an external scrubber for
producing zero air and two valves for switching between the sample gas inlet and the
output of the zero/span subsystem, functionally identical to the zero/span valve option.
The IZS option includes a two stage, external zero air scrubber assembly that removes all
NO & NO
2
from the zero air source. The scrubber is filled with 50% Purafil Chemisorbant
®
(for conversion of NO to NO
2
) and 50% activated charcoal (for removal of NO
2
). This
assembly also includes a small particle filter.
Span gas is created by passing zero air over a NO
2
permeation tube. This tube contains
liquid NO
2
, which slowly permeates through a permeable membrane into the surrounding
air. The concentration of the NO
2
span gas is determined by three factors:
Size of the membrane: The larger the area of the membrane, the more permeation
occurs.
Temperature of the NO
2
: Increasing the temperature of the permeation tube
increases the pressure inside the tube and therefore increases the rate of
permeation.
044100102 Rev A 35
