Model 200E Instruction Manual APPENDIX B

Part Number Description Notes Qty

046060000 AKIT, ORIFICE EXPENDABLES,

M200Ex

Expendables kit for one orifice

assembly

This kit contains the following items

FL0000001 FILTER, SS Sintered stainless steel filter 1

HW0000020 SPRING Spring to hold assembly in place 1

OR0000001 ORING, 2-006VT O-ring to seal critical orifice 2

Quantity included in one kit.

044100120 Rev A 255
