Model 200E Instruction Manual Operating Instructions
Setting analog range limits to different values does not affect the instrument’s calibration.
To select the IND range mode, press the following keys:
SAMPLE RANGE = 500.0 PPB NOX=X.X
< TST TST > CAL
SETUP
SETUP X.X
PRIMARY SETUP MENU
CFG DAS
RNGE
PASS CLK MORE EXIT
SETUP X.X
RANGE CONTROL MENU
MODE
SET UNIT EXIT
SETUP X.X RANGE MODE:
SNGL
SNGL
IND
AUTO ENTR EXIT
SETUP X.X RANGE MODE:
IND
SNGL DUAL AUTO
ENTR EXIT
EXIT
ignores the new setting and returns to the
RANGE CONTROL MENU
.
ENTR
accepts the new setting and returns to the
RANGE CONTROL MENU
.
To set the range value for each independent range, press:
SETUP X.X
RANGE CONTROL MEN
U
MODE
SET
UNIT EXIT
SETUP X.X
NO RANGE: 500.0 Conc
0 1 0 0 0 .0 ENTR
EXIT
SETUP X.X
NOX RANGE: 500.0 Conc
0 1 5 0 0 .0 ENTR
EXIT
SETUP X.X
NO2 RANGE: 500.0 Conc
0 0 5 0 0 .0 ENTR EXIT
Press the
numeral keys to
set range value
EXIT
ignores the new setting and returns to the
RANGE CONTROL MENU
.
ENTR
accepts the new setting and returns to the
RANGE CONTROL MENU
.
SAMPLE RANGE = 500.0 PPB NOX=X.X
< TST TST > CAL
SETUP
SETUP X.X
PRIMARY SETUP MENU
CFG DAS
RNGE
PASS CLK MORE EXIT
