To access and navigate the VARS menu, use the following key sequence:
SAMPLE RANGE = 500.0 PPB NOX=X.X
< TST TST > CAL SETUP
SETUP X.X
PRIMARY SETUP MENU
CFG DAS RNGE PASS CLK MORE EXIT
SETUP X.X
SECONDARY SETUP MENU
COMM VARS DIAG EXIT
SETUP X.X 0 ) DAS_HOLD_OFF=15.0 Minutes
NEXT JUMP EDIT PRNT EXIT
SETUP X.X 1 ) TPC_ENABLE=ON
PREV NEXT JUMP EDIT PRNT EXIT
SETUP X.X 4) SFLOW_SET=500.0 cc/m
PREV NEXT JUMP EDIT PRNT EXIT
SETUP X.X ENTER VARS PASS: 818
8 1 8 ENTR EXIT
SETUP X.X DAS_HOLD_OFF=15.0 Minutes
1 5 .0 ENTR EXIT
SETUP X.X 5) OFLOW_SET=80.0 cc/m
PREV NEXT JUMP EDIT PRNT EXIT
SETUP X.X 6) IZS_SET=80.0 cc/m
PREV NEXT JUMP EDIT PRNT EXIT
DO NOT change
theses set-points
unless
specifically
instructed to by
T-API Customer
Service.
SETUP X.X CLOCK_ADJ=0 Sec/Da
+ 0 0 ENTR EXIT
SETUP X.X 7) CLOCK_ADJ=0 Sec/Day
PREV
NEXT
JUMP
EDIT
PRNT EXIT
EXIT ignores the new setting.
ENTR accepts the new setting.
SETUP X.X 1 ) TPC_ENABLE=ON
ON ENTR EXIT
SETUP X.X 2 ) DYN_ZERO=ON
PREV NEXT JUMP EDIT PRNT EXIT
SETUP X.X
2 ) DYN_ZERO=ON
ON ENTR EXIT
Toggle this keys to change setting
Toggle this keys to change setting
SETUP X.X 3) DYN_SPAN=ON
PREV NEXT JUMP EDIT PRNT EXIT
SETUP X.X 3 ) DYN_SPAN=ON
ON ENTR EXIT
Toggle this keys to change setting
Toggle this keys to change setting
SETUP X.X 8) CAL_ON_NO
2
= OFF
PREV
NEXT
JUMP
EDIT
PRNT EXIT
SETUP X.X 8) C
L_ON_NO
2
= ON
ON ENTR EXIT
Toggle this keys to change setting
Toggle this keys to change setting
