4.31 For Tellabs 7325 Switch LED descriptions and states, refer to Table 4.7,
page 2-36.
60.0273 GMT 3.0A Fuse
60.0088 GMT 5.0A Fuse
163.006 GMT 7.5A Fuse
81.73GND-KIT-R6
1
7300 Universal Grounding Kit
81.73W-25SCA-R5 7300 Serial Port Adapter
81.S1GBER450010 SFP: 10/100/1000 BaseT RJ-45
81.S1GBESX1851M SFP: SR/SX, 850 nm, MM
81.S1GBELX1131S SFP: LX, 1310 nm, SM
81.S1GBEZX1151S SFP: ZX, 1550 nm, SM
81.S125M000132M
2
SFP: 125 Mbps, 2 km, 1310 nm, MM
81.S125M000132S SFP: 125 Mbps, 10 km, 1310 nm, SM
81.S1GBER450030 SFP: GBE, Electrical, RJ-45, I-TEMP
81.S1GBESX1853M SFP: GBE/FC/FICON, SR/SX, 850 MM, I-TEMP
81.S1GBELX1133S SFP: GBE/FC/FICON, LX, 1310 SM, I-TEMP
81.S1GBEZX1153S SFP: GBE/FC/FICON, ZX, 1550 SM, I-TEMP
81.S125M000133M
2
SFP: 100BaseFX (125Mbps) - 2km, 1310 MM, I-TEMP
81.S125M000133S SFP: 100BaseFX (125Mbps) - 10km, 1310 SM, I-TEMP
1. Replacement or spare parts only.
2. Use only with 62.5 micron multi-mode fiber.
Table 4.6 Available Hardware for Tellabs 7325 Switch
Tellabs Part Number Description
Table 4.7 Tellabs 7325 Switch LED Descriptions
LED Status Description
Active green The Tellabs 7325 Switch is active and provisioned to the
UP state.
green flashing Initial bootup or during upgrade when writing to flash.
red The Tellabs 7325 Switch is faulted (in the DOWN
operational state).
Power green Both -48V power supplies are present and both -48V
fuses are intact.
red The Tellabs 7325 Switch is faulted (in the DOWN
operational state).
off The Tellabs 7325 Switch has no power or the LED is not
functional.
