Temptronic ThermoStream TP04300 Series User Manual

3
SYSTEM OPERATION
Operator Screen (Full Access)
3-22 TP04300 Series Interface & Applications Manual
Cycle Pointer Appears when the system is cycling.
Points to the setpoint the system is presently cycling to.
Temperature
Pointers
Appears when the system is ramping to or at the selected setpoint.
A second “green” pointer appears when the air flow is On.
About Button Press to display information on the system, including software
version.
Operator Screen
Tabs
Press to display each of the major screens: Operator, Cycle,
Utilities, Setup, History, Datalog.
Cycles:1 Press to set the number of cycles.
1 cycle is completed when the system goes through each of the
three setpoints (HOT, COLD, AMBIENT).
Start Cycling Press to begin the cycling routine.
NOTE: the Flow must be set to ON for cycling to begin.
Pause Cycling Press to Pause the cycling routing
Cycle Segment
Table
Displays the profiles of the 3 programmed setpoints (HOT,
AMBIENT, COLD).
NOTE: the cycle information may be toggled on/off in the Setup
Screen.
Run to Setpoint Press Run to Setpoint and then either HOT, COLD, or AMBIENT
to run the system to 1 setpoint.
Change Setpoint Press Change Setpoint and then either HOT, COLD, or AMBIENT
to change the temperature of the selected setpoint
Change Soak Time Press Change Soak Time and then either HOT, COLD, or
AMBIENT to change the soak time of the selected setpoint
Soak time is the duration that the system will stay (or soak) at the
setpoint.
Change Ramp Rate Press Change Ramp Rate and then either HOT, COLD, or
AMBIENT to change the ramp rate of the selected setpoint
NOTE: a RAMP set to “0” will not allow the system to change (or
ramp to) temperature. When cycling, a setpoint with a RAMP set to
“0” will be skipped.
A RAMP set to “9999” will allow the system to change (or ramp to)
temperature at its fastest rate.
Change Window Press Window and then either HOT, COLD, or AMBIENT to
change the window of the selected setpoint.
Window is the range above/below the setpoint, in which the system
is "At Temperature."
Example: a 50 °C setpoint, with 1.0 °C Window is "At Temp"
between 49 to 51 °C.
Head Up/Down Press to toggle the Thermal head up or down.
Flow On Press to toggle main air flow on or off.
Field/Button Description
