Ethernet Connector

Introduction An industry standard RJ-45 port is provided for 10/100 BaseT Ethernet communications. It

supports:

• 10 Mb/s and 100 Mb/s operation (N-way auto-negotiation)

• Full duplex capability

• Full duplex flow control per IEEE 802.3x

RJ-45 Connector

(Pin Outs)

Pin Signal

1 Transmit + (positive)

2 Transmit - (negative)

3 Receive + (positive)

4 Not Connected

5 Not Connected

6 Receive - (negative)

7 Not Connected

8 Not Connected
