Temptronic ThermoStream TP04300 Series User Manual

. . . . .
REMOTE INTERFACES
Device Specific Commands
TP04300 Series Interface & Applications Manual 4-17
Device Specific Commands
Command Description
ADMD Set the air-to-DUT maximum difference.
ADMD nnn -- where nnn is 10 - 300 °C in 1 degree increments.
ADMD? Read the air-to-DUT maximum difference.
AUXC? Read the auxiliary condition register.
Version 3 software:
bit 10 – reserved
bit 9 – reserved
bit 8 – Operator screen = 1, Cycle screen = 0
bit 7 – reserved
bit 6 – ready for operation = 1, startup sequence = 0
bit 5 – flow on = 1, flow off = 0
bit 4 – DUT mode = 1, air-control mode = 0
bit 3 – heat only mode =1, compressor on =0
bit 2 – head up = 1, head down = 0
bit 1 – reserved
bit 0 – reserved
Version 1 software:
bit 17 – HDLK
bit 16 – MCTP
bit 15 – DTYP
bits 12/13/14 – DSNS
• 0/ 0 /0 – no DUT sensor present
• 0/ 0 /1 – type T thermocouple
• 0/ 1/ 0 – type K thermocouple
• 0 /1/ 1 – RTD
• 1/ 0 /0 – diode
bits 10/11 – DUTM
•0/ 0 -- air
• 0/ 1 – DUT
bit 9 – DLOG
bit 8 – CYCP
bit 7 – CYCL
bit 6 – TRKL
bit 5 – COOL
bit 4 – FLOW
bit 3 – HEAD
bit 2 – EROR
bit 1 – EMSH
bit 0 – N/A
