4
REMOTE INTERFACES
MCT Interface
4-30 TP04300 Series Interface & Applications Manual
Section K:
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
MCT Interface
MCT Interface
This interface has 2 inputs:
• End of Test (EOT) and Stop On First Fail (SFF),
and one output:
• Start Test (ST).
To set the input/output pulse polarity, use “MCT Polarity: Positive/Negative” on the Utilities
Screen (see Chapter 3 for more information on the Utilities screen.
MCT Interface
SFF
