Temptronic ThermoStream TP04300 Series User Manual

. . . . .
PREPARATION FOR USE
Compressed Air Standards
TP04300 Series Interface & Applications Manual 2-27
Compressed Air Standards
The TP04300 is supplied with a 3 meter long, 5/8-inch ID braid reinforced, rubber hose and its
associated 1/2-inch NPT barb fitting and two hose clamps.
Compressed Air
Requirements
Air Dryer
The air dryer is fully integrated into the TP04300 pneumatics package. To enable air dryer
function, simply connect the air supply.
The supply flow must be capable of the specified minimum SCFM: a supply pressure below
the minimum results in a reduced performance.
Clean, Dry Air Filtered to 5 micron particulate contamination
Supply Pressure 6.2 to 7.6 BAR (90 to 100 PSIG)
Supply Flow at
minimum supply
pressure
7.2 I/s to 14.3 I/s (9 to 30 scfm)
Air Supply
Temperature
+20 to +25C (+22C nominal)
Operating
Temperature
+20 to +28C (+23C nominal)
Humidity 0 - 60% (45% nominal)
