ROUTINE MAINTENANCE
Air Sensor Calibration (Air Mode)
TP04300 Series Interface & Applications Manual 5-23
Air Sensor Calibration (Air Mode)
Start Calibrating (Air
Sensor)
Procedure To calibrate the main Air sensor:
Step Action
1 Run system for half an hour at Ambient to stabilize components at normal
operating temperatures.
2 Toggle Head into Up position so System is not supplying main air flow
controlled to a setpoint (other than "Trickle" air flow).
NOTE: 4300B Systems should have the “Head: Lock” on. The “Head: Lock”
can be toggled on/off in the Utilities Screen.
3 Remove the Air sensor access cover on the Head rear.
To Next Page
