REMOTE INTERFACES
MCT Interface
TP04300 Series Interface & Applications Manual 4-31
MCT Connector, Pin
Outs
Pin # Signals Functions
1 STOP, FIRST FAIL An input pulse as short as 11 msec received
to signal the System (when in cycle mode) to
abort temperature cycling and to display
“DUT Failure” alert.
10 START TEST
(READY TO TEST)
An output (120 to 150 msec pulse) from the
System to signal AT TEMP condition.
11 TESTER VCC +5 to +12 Vdc
12 TESTER GROUND Ground
24 END OF TEST An input (as short as 11 msec pulse) to the
System which when in cycle mode will limit
the maximum set test time.
