5
ROUTINE MAINTENANCE
Low Temperature Verification
5-16 TP04300 Series Interface & Applications Manual
Verify DUT “Diode”
(Low Temp.)
Step Action
34 To verify a Diode sensor, first calibrate the Diode
(see Calibration, page 5-20)
35 After calibrating the Diode, then an external Type T or Type K sensor may be
interfaced to the Diode and can be read to verify the calibration.
36 Temperature accuracy (the acceptable temperature range above/below setpoint)
will vary based on the chosen Diode’s linearity.
