SYSTEM OPERATION
OCM User Interfaces
TP04300 Series Interface & Applications Manual 3-11
OCM Cable Ports The OCM Cable Ports are installed on the system front panel, located
within the top panel overhang, to the right side of the 3.5 inch diskette
drive, consisting of ports for a Keyboard, mouse, USB connection (2),
and printer.
Keyboard Port: a DIN port (recessed and facing down) used to interface
a keyboard
Mouse Port: a DIN port (recessed and facing down) used to interface a
mouse
USB Port: (2) standard USB ports
3.5” Diskette
Drive
The drive uses standard, high-density, 3-1/2 inch 1.44-MB diskettes
• use drive to transfer files: datalog, test setup, test data
• use drive to load updated operating system files
EMO Switch Press the EMO to trip the back panel Circuit Breaker (CB1) and
interrupt the power input to the TP04300 (shutting down the system).
Power ON/Off
Switch
The system’s on/off power switch. The indicator light illuminates when
the system is on.
Help (On Screen) an on screen “HELP” button located on the lower right of the touch
screen.
