Split Screens 509
Voyage™ 200:
Exiting the Split Screen Mode
Exiting the Split Screen ModeExiting the Split Screen Mode
Exiting the Split Screen Mode
TOP–BOTTOM
1:1 0 – 154 0 – 34 0 – 154 0 – 34
LEFT–RIGHT
1:1 0 – 76 0 – 72 0 – 76 0 – 72
Split 1 App Split 2 App
Split Ratio x y x y
FULL
N/A 0 – 238 0 – 102 N/A N/A
TOP–BOTTOM
1:1
1:2
2:1
0 – 234
0 – 234
0 – 234
0 – 46
0 – 26
0 – 68
0 – 234
0 – 234
0 – 234
0 – 46
0 – 68
0 – 26
LEFT–RIGHT
1:1
1:2
2:1
0 – 116
0 – 76
0 – 156
0 – 98
0 – 98
0 – 98
0 –116
0 – 156
0 – 76
0 – 98
0 – 98
0 – 98
Method 1: Press 3 to display the MODE dialog box. Then
set
Split Screen = FULL. When you press ¸ to
close the dialog box, the full-sized screen shows the
application specified in
Split 1 App.
Split 1 App Split 2 App
Split Ratio x y x y
