Appendix A: Functions and Instructions 827
Goto CATALOG
Goto
labelName
Transfers program control to the label
labelName
.
labelName
must be defined in the same program
using a
Lbl instruction.
Program segment:
©
:0! temp
:1! i
:Lbl TOP
: temp+i! temp
: If i<10 Then
: i+1! i
: Goto TOP
: EndIf
:Disp temp
©
4
44
4Grad CATALOG/MATH/Angle menu
4
44
4 Grad
expression
Converts an expression to gradian angle measure.
In Degree angle mode:
1.5 4Grad ¸ 1.66667
G
In Radian angle mode:
1.5 4Grad ¸ 95.493
G
Graph CATALOG
Graph
expression1
[,
expression2
] [,
var1
] [,
var2
]
The Smart Graph feature graphs the requested
expressions/ functions using the current graphing
mode.
Expressions entered using the
Graph or Table
commands are assigned increasing function
numbers starting with 1. They can be modified or
individually deleted using the edit functions
available when the table is displayed by pressing
† Header. The currently selected Y= functions
are ignored.
If you omit an optional
var
argument, Graph uses
the independent variable of the current graphing
mode.
Note: Not all optional arguments are valid in all
modes because you can never have all four
arguments at the same time.
In function graphing mode and
ZoomStd window:
Graph 1.25aù cos(a),a ¸
In parametric graphing mode and ZoomStd window:
Graph time,2cos(time)/time,time ¸
Some valid variations of this instruction are:
Function graphing
Graph
expr
,
x
Parametric graphing
Graph
xExpr
,
yExpr
,
t
Polar graphing
Graph
expr
, q
Sequence graphing Not allowed.
3D graphing
Graph
expr
,
x
,
y
Diff Equations graphing Not allowed.
Note: Use
ClrGraph to clear these functions, or
go to the Y= Editor to re-enable the system Y=
functions.
In 3D graphing mode:
Graph (v^2 ì w^2)/4,v,w ¸
