Textron Jacobsen InCommand PGM 22 - Page 40

3-10 4157082 First Edition
ENGINE
3
Figure 3-19
20. Loosen two set screws (42) and remove clutch (43)
from engine output shaft.
Figure 3-20
21. Remove key (48) from engine output shaft (46).
22. Remove two screws (44), washers (45), and cover
(47) from engine.
Figure 3-21
23. Remove four nuts (53), lock washers (52), carriage
bolts (51), and mounting plate (50) from engine (49).
TN0076
43
42
TN0077
44
45
47
48
44 45
46
TN0045
49
53
52
51
50
