Electrical specifications
WARNING! For safety, the power outlet used for powering the instrument must be
accessible at all times. In case of emergency, you must be able to immediately
disconnect the main power supply to all the equipment. Allow adequate space
between the wall and the equipment so that the power cords can be disconnected in
case of emergency.
IMPORTANT! Use only the approved power supply provided by Thermo Fisher
Scientic to power the QuantStudio
™
3D Digital PCR Chip Loader.
•
Electric receptacle is required
•
Mains AC line voltage tolerances must be up to ±10% percent of nominal
voltage
Note: Place the instrument power receptacle on an electrical circuit that is not
shared with electrically noisy devices or devices that can cause power surges, such
as refrigeration units.
The following table provides electrical specications for the instrument and
associated devices. For all indicated input voltages, a 15A circuit is required.
Device
Rated
voltage
Rated
frequency
Rated
current
Rated
power
QuantStudio
™
3D
Digital PCR Instrument
100–
240 VAC
[1]
50/60 Hz 150 mA 10 VA
QuantStudio
™
3D
Digital PCR Chip Loader
12 VDC – – 2.5 A max
ProFlex
™
2 × Flat PCR
System
See the ProFlex
™
PCR System User Guide
(Pub. No. MAN0007697) for the ProFlex
™
2 × Flat PCR
System electrical requirements.
Dual Flat Block GeneAmp
™
PCR System 9700
See the GeneAmp
™
PCR System 9700 Base Module User
Manual (Pub. No. 4303481) for the GeneAmp
™
PCR
System 9700 electrical requirements.
[1]
If the supplied power fluctuates beyond the rated voltage, a power line regulator may be required. High or
low voltages can adversely affect the electronic components of the instrument.
