Topcon X14 - Page 15

xi
5.2.1. Receiver setup 29
5.2.2. Correction setup 30
5.3. Setting up alarms 34
5.3.1. Alarm window description 34
5.3.2. Alarms list 35
5.4. Setting up flag points 38
5.5. Setting up utilities 39
Chapter 6 – Vehicle Setup 41
6.1. Selecting a vehicle 42
6.2. Creating a new vehicle 42
6.2.1. Customizing a vehicle 43
6.3. Setting the vehicle geometry 43
6.4. Setting up the steering controller 45
6.5. Selecting the vehicle antenna 46
Chapter 7 – Implement Setup 47
7.1. Selecting an implement 48
7.2. Setting up a new implement 48
7.3. Setting the implement geometry 49
7.4. Setting up section control 50
7.4.1. Setting timing 50
7.4.2. Setting up the section switch 51
7.5. Setting up the master switch 51
7.6. Setting up GPS speed emulation 52
Chapter 8 – Product Setup 53
8.1. Setting up the product database 53
Chapter 9 – Operation Basics 55
9.1. Using the window toolbar 55
9.2. Using the navigation window 55
9.3. Viewing guidance 56
9.3.1. Using view controls 56
9.4. Viewing GPS information 60
9.5. Viewing system diagnostics 61
9.6. Viewing job information 61
9.7. Monitoring on the dashboard 62
