Chapter 3 – Quick Setup Guide

Enable the Auto Section Control feature in System /

Features / Implement / AUTO SECTION

CONTROL (see page 28).

12. To control any of the enabled features from the Operation screen,

use the buttons on the Navigation window (see page 55).
