Toro Reelmaster 3100-D Service Manual

GeneralInformation
Operator’sManual
TheOperator’sManualprovidesinformationregardingtheoperation,general
maintenanceandmaintenanceintervalsforyourReelmastermachine.Referto
theOperator’sManualforadditionalinformationwhenservicingthemachine.
ElectricalDrawings
TheelectricalschematicandwireharnessdrawingsfortheReelmaster3100−D
andtheReelmaster3105−DarelocatedinChapter9−FoldoutDrawings.
StandardControlModule(SCM)
AllReelmaster3100–Dand3105–DmachinesareequippedwithaStandard
ControlModule(SCM)tomonitorandcontrolelectricalcomponentsrequiredfor
safeoperation.TheSCMcanbeusedtocheckoperationofmachineswitches
bymonitoringtheSCMLED’s.DetailedinformationontheStandardControl
Modulecanbefoundlaterinthischapter.
DieselEngine−ElectricalComponents
TheengineusedintheReelmasterincorporatesthefollowingelectrical
componentstostartandrunproperly:
•Glowplugcontrollerandrelay
•FuelstopSolenoid
•HighTempWarningandShutdownSwitches
•OilPressureSwitch
•Alternator
Additionalinformationontroubleshootingandservicingengineelectrical
componentscanbefoundintheappropriateKubotaWorkshopManual
.
ElectricalSystem:GeneralInformation
Page6–2
Reelmaster
®
3100-D/3105-D
20252SLRevA
