ShopRollerAssembly(Model03192)
g348049
Figure187
1.Clevispin
5.Washer
2.Carriagebolt6.Spacer
3.Cotterhairpin
7.Roller
4.Flangeheadnut8.Rollerbracket
RemovingtheShopRollerAssembly
1.Positionmachineonacleanandlevelsurface,lowercuttingunits,stop
engine,engageparkingbrakeandremovekeyfromthekeyswitch.
IMPORTANT
Beforethecuttingunitsareloweredtotheshopoororremoved
fromthetractionunit,lowertheshoprollerassembliestoprotectthe
reelandbedknifebladesfromhardsurfacecontact.
2.Removethecotterhairpinfromtheclevispinthatsecurestheshoproller
brackettothesideplate.
3.Removetheshoprollerassemblyfromthecuttingunit.
4.DisassembletheshoprollerassemblybyusingtheFigure187asaguide.
InstallingtheShopRollerAssembly
1.AssembletheshoprollerassemblybyusingtheFigure187asaguide.
2.Installtheshoprollerassemblyontothesideplateofthecuttingunit.
3.Securetheshoprollerassemblywithclevispinandcotterhairpin.
IMPORTANT
Ensurethattheclevispinisalwaysinstalledinthetopsquarehole
inthesideplate.
4.Adjusttheshoprollerassembly;refertoCuttingUnitOperator’sManual.
Reelmaster
®
3100-D/3105-D
Page8–33
DPACuttingUnits:ServiceandRepairs
20252SLRevA
