FrontWheelMotors
g345325
Figure79
1.Hydraulictube10.Locknut19.Bolt
2.O-ring
11.Brakeassembly20.Brakelever
3.Hydraulictting
12.Bolt
21.Cotterpin
4.O-ring
13.Brakedrum22.Adjustmentrod
5.Socketheadscrew
14.Wheelhub
23.Clevispin
6.Hydraulicmotorassembly15.Wheelassembly
24.Cotterpin
7.Pulleydeckspacer16.Locknut25.Locknut
8.Wheelshield17.Lugnut26.Retainingring
9.Brakebracket18.Drivestud
RemovingtheFrontWheel(Figure79)
1.Parkthemachineonalevelsurface.Lowercuttingunits,stopengineand
engageparkingbrake.Removekeyfromthekeyswitch.
WARNING
Beforejackingupthemachine,reviewandfollowJacking
Instructions(page1–7).
HydraulicSystem:ServiceandRepairs
Page5–96
Reelmaster
®
3100-D/3105-D
20252SLRevA
