Toro Reelmaster 3100-D Service Manual

ServiceProcedureIcons
ThefollowingiconsappearthroughoutthisServiceManualtobringattentionto
specicimportantdetailsofaserviceprocedure.
CriticalProcess
Thisiconisusedtohighlight:
•installingsafetyequipment(shields,guards,seatbelts,brakesandR.O.P .S.
components)thatmayhavebeenremoved.
•dimensionsorsettingsthatmustbemaintainedforpropermachineoperation.
•aspecicfastenertighteningsequence.
•componentorientationthatmaynotbeobvious.
CriticalTorque
Thisiconisusedtohighlightanassemblytorquerequirementthatisdifferent
thanwhatisrecommendedintheStandardTorqueT ables;refertoT orque
Specications(page2–5).
FluidSpecications
Thisiconisusedtohighlightuidspecicationsandcapacitiesthatareless
common,andmaynotappearonthemachineservicedecalorinthemachine
Operator’sManual.
Note:RefertotheservicedecalonthemachineandthemachineOperator’s
Manualforcommonlyuseduidspecicationsandcapacities.
Reelmaster
®
3100-D/3105-D
Page7
Preface
20252SLRevA
