Toshiba TOSVERT VF-AS3 User Manual

E6582062
11. Table of parameters 11-36
1
9
11
F661 0661
Override multiplying
input select
0: -
1: Terminal RR
2: Terminal RX
3: Terminal II
4: Terminal AI4 (option)
5 - 11: -
12: F729
13 - 23: -
- - 0 Y [6. 32]
F664 0664 Specified trip 1 0 - 100 Times 1/1 0 N
[6. 30. 21]F665 0665 Specified trip 2 0 - 100 Times 1/1 0 N
F666 0666 Specified trip 3 0 - 100 Times 1/1 0 N
F667 0667
Pulse output step of
input cumulative
power
0: 0.1kWh
1: 1kWh
2: 10kWh
3: 100kWh
4: 1000kWh
5: 10000kWh
--1Y
[6. 33. 1]
F668 0668
Pulse output width
of input cumulative
power
0.1 - 1.0 s 0.1 Y
F669 0669
Terminal FP
switching
0: Digital output
1: Pulse output
--0N
[6. 33. 2]
[7. 2. 2]
F670 0670
Terminal AM
function
0 - 162
*3
--2Y
[5. 2. 6]
F671 0671
Terminal AM
adjustment
----Y
F676 0676
Terminal FP pulse
train output function
0 - 149
*3
--0Y
[6. 33. 2]F677 0677
Maximum pulse
number of pulse
train output
0.50 - 43.20 kpps 8.00 Y
F678 0678
Pulse train output
filter
1 - 1000 ms 64 Y
F679 0679
Pulse train input
filter
1 - 1000 ms 1 Y [6. 6. 4]
F681 0681
Terminal FM
switching
0: Meter option (0-1mA)
1: Current output
(0-20mA)
2: Voltage output
(0-10V)
--2N
[6. 33. 3]
F682 0682
Terminal FM
inclination polarity
0: Negative inclination
(downward slope)
1: Positive inclination
(upward slope)
--1Y
Title
Communication
No.
Parameter name Adjustment range Unit
Minimum
setting unit
(Panel/
Communication)
Default
setting
Write
during
running
*6
User
setting
Reference

Toshiba TOSVERT VF-AS3 Specifications

General

Model	TOSVERT VF-AS3
Category	Inverter
Overload Capacity	150% for 60 seconds
Cooling Method	Forced Air Cooling
Control Method	V/f control, Sensorless vector control
Braking Unit	Built-in
Communication Protocols	Modbus RTU, DeviceNet, Profibus DP
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheat, Ground Fault
Enclosure	IP20
Operating Temperature	-10°C to +50°C
Humidity	5-95% (non-condensing)
Altitude	Up to 1000m
