Technical data
16 OM 100.EPW400.202002.en
3.1.4 Digital inputs
16 digital inputs
Isolated
Input voltage
24 V (permissible range: -30 V to +30 V)
Input current
At rated voltage (24 V): 6.1 mA
Delay time of standard inputs
tLOW-HIGH 3.5 ms
tHIGH-LOW 2.8 ms
Input voltage
LOW level: ≤ 5 V
HIGH level: ≥ 15 V
Input current
LOW level: ≤ 1.5 mA
HIGH level: ≥ 3 mA
Input impedance 3.9 kΩ
3.1.5 Digital outputs
8 digital outputs
Isolated
Load voltage Vin
Rated voltage 24 V
(permissible range 18 V to 30 V)
Output voltage
HIGH level min. Vin-0.64 V
LOW level max. 100 µA • RL
Output current
max. 500 mA
Parallel connection of outputs possible
Max. 4 outputs with Itot = 2 A
Short-circuit proof
Yes, thermal overload protection
Switching frequency
Resistive load 100 Hz
Inductive load 2 Hz (dependent
on inductance)
Lamp load max. 6 W
Simultaneity factor 100%
Avoid reversing current
Reversing current at the outputs may damage the output drivers.
On devices with field bus interface, the outputs, such as "Ready for operation", are
written on both the digital outputs and the field bus outputs. Whether the inputs are
read on the digital inputs or on the field bus inputs is determined in menu 'Additional-
>Communication parameters->Anybus-S Subprint'.
