Configuring the EPW 400
OM 100.EPW 400.202002.en 79
6.2.22 Distance sensor calibration
Calibration:
This function is used to specify the allocation of the electric measuring
signal and of the measuring variable to be displayed. This is a pure two-
point calibration.
Distance 1:
To teach, click on button 'Teach'.
Read in the current electric measuring signal.
Tap on the 'Distance 1' input field.
A window will open with a numerical keypad.
Enter the value of the measuring value to be displayed for the electric measuring
signal and confirm this value with the 'Enter' button.
It is also possible to enter the electric measuring signal numerically by tapping on the
input field.
