TOX EPW400 User Manual

Technical data
42 OM 100.EPW400.202002.en
3.4.2 Fieldbus interface
Data length: Byte 0-2
Inputs I0-I15
Designation
Field bus byte
Field bus bit
I 0 Program bit 0 0 0
I 1 Program bit 1 0 1
I 2
Program bit 2
0
2
I 3 Program bit 3 0 3
I 4
Program bit 4
0
4
I 5 Program bit 5 0 5
I 6 Program strobe 0 6
I 7 Offset external 0 7
I 8
Start measurement
1
0
I 9 Reserve 1 1
I 10 Control panel inter-
lock
1 2
I 11 Error reserve 1 3
I 12 Reserve 1 4
I 13 Configurable input 1 5
I 14
Access level bit 1
1
6
I 15 Reserve 1 7
Outputs Q0-Q7 Designation Field bus byte Field bus bit
Q 0 OK 0 0
Q 1 NOK 0 1
Q 2 NOK alarm 0 2
Q 3 Switching point S1
5
0 3
Q 4 Switching point S2
5
0 4
Q 5 Ready for measure-
ment
0 5
Q 6 Program ACK 0 6
Q 7 Switching point S3
5
0 7
5
Output function options:
Switching point S1 / Enable
Switching point S2 / Buzzer
Switching point S3 / Warning piece counter
