Technical data
OM 100.EPW 400.202002.en 43
Format of final values via fild bus (bytes 3 – 63):
The end values are written on bytes 3 to 55 on the field bus (if this function is acti-
vated).
• Byte X (structure):
7 6 5 4 3 2 1 0 Byte X
Byte 3: Status (Status 2 = OK / Status 3 = NOK)
Byte 4, 5, 6, 7: Running number
Byte 8: Program
Byte 9: Reserve
Byte 10, 11: Max. force [kN] * 100
Byte 12, 13: Max. distance [mm] * 100
Byte 14: Second
Byte 15: Minute
Byte 16: Hour
Byte 17: Day
Byte 18: Month
Byte 19: Year
Byte 20, 21: Window 1, actual force [kN] * 100 (for actual distance [mm])
Byte 22, 23: Window 1, force upper limit [kN] * 100
Byte 24, 25: Window 1, force lower limit [kN] * 100
Byte 26, 27: Window 1, actual distance [mm] * 100
Byte 28, 29: Window 1, distance upper limit [mm] * 100
Byte 30, 31: Window 1, distance lower limit [mm] * 100
Byte 32, 33: Window 2, actual force [kN] * 100 (for actual distance [mm])
Byte 35, 35: Window 2, force upper limit [kN] * 100
Byte 36, 37: Window 2, force lower limit [kN] * 100
Byte 38, 39: Window 2, actual distance [mm] * 100
Byte 40, 41: Window 2, distance upper limit [mm] * 100
Byte 42, 43: Window 2, distance lower limit [mm] * 100
Byte 44, 45: Window 3, actual force [kN] * 100 (for actual distance [mm])
Byte 46, 47: Window 3, force upper limit [kN] * 100
Byte 48, 49: Window 3, force lower limit [kN] * 100
Byte 50, 51: Window 3, actual distance [mm] * 100
Byte 52, 53: Window 3, distance upper limit [mm] * 100
Byte 54, 55: Window 3, distance lower limit [mm] * 100
Byte 56, 57: Actual value force [kN] * 100
Byte 58, 59: Actual value distance [mm] * 100
Byte 60 - 63: Reserve
