Configuring the EPW 400
OM 100.EPW 400.202002.en 87
6.2.36 Configuring the analog outputs
Depending on requirements, the relationship between outputs 0 and 1 can be defined
here.
Selection
Function
Output 0:
Actual distance
value [V]
Outputs the actual value of the distance
sensor
Actual force value
[V]
Outputs the actual value of the force sen-
sor
Tare signal
Outputs a tare signal
Deactivated
Output 0 is deactivated
Output 1:
Actual distance
value [V]
Outputs the actual value of the distance
sensor
Actual force value
[V]
Outputs the actual value of the force sen-
sor
Process-dependent
value
Outputs a predefined voltage which is set
in the 'Switching points' menu
Deactivated
Output 1 is deactivated
Close the 'Configure analog outputs' window by tapping on the "Accept"
button. The configuration will be adopted.
