Technical data
OM 100.EPW 400.202002.en 33
3.3.3 Wall-mounted housing: digital inputs I0-I15 (25-pin D-sub female connector)
Pin, D-SUB
25
OK Color code Designation
14 I0 White Program bit 0
15 I1 Brown Program bit 1
16 I2 Green Program bit 2
17 I3 YELLOW Program bit 3
9 I4 White-blue
3
Program bit 4
10 I5 Brown-blue
3
Program bit 5
18 I6 Grey Program strobe
19 I7 White-yellow Offset external
20 I8 White-grey Start measurement
I9 Reserve
21 I10 White-pink Control panel interlock
22 I11 Brown-red
3
Error reset
I12 Reserve
13 I13 White-red
3
Configurable input
25 I14
3
Access level bit 1
12 0 V Brown-green 0 V external (PLC)
11 0 V internal Blue 0 V internal
23 24 V inter-
nal
Pink +24 V from internal (source)
3.3.4 Wall-mounted housing: digital outputs Q0-Q7 (25-pin D-sub female connector)
Pin, D-SUB
25
OK
Color code
Designation
1 Q0 Red OK
2 Q1 Black NOK
3 Q2 Yellow-
brown
NOK alarm
4 Q3 Violet Switching point S1
4
/ Enable
5 Q4 Grey-brown Switching point S2
4
/ NOK buzzer
6 Q5 Grey-pink Ready for measurement
7 Q6 Red-blue Program ACK
8 Q7 Pink-brown Switching point 3
4
/ item quantity warning
12 0 V Brown-green 0 V external (PLC)
24 24 V White-green +24 V external (PLC)
3
Must be connected later
4
Output function configurable
