Operating the device
48 OM 100.EPW400.202002.en
Menu
Opens the 'Maintenance' menu
Error reset
Resets an error. This button appears only in
case of an error.
Firmware version
Reads the firmware version.
5.3.2 Icons
Measure OK
The last measurement was OK
Measurement NOK
Last measurement was not OK. At least one
evaluation criterion was violated (envelope /
window)
Measure active
Measurement is running, values are being rec-
orded.
Measurement
stopped manually
Measurement stopped by clicking on symbol
'Measurement OK', 'Measurement NOK', or
'Measurement running'. Enable the measure-
ment by clicking on symbol 'Measurement
stopped'.
Device ready to
measure
EPW 400 is ready to start a measurement.
Device not ready to
measure
EPW 400 not ready to start a measurement.
Fault
Device signals an error. The exact cause of the
error is highlighted in red at the top of the
screen.
Ethernet interface
not initialized
Connection via Ethernet to a PC not yet possi-
ble.
Ethernet interface ini-
tialized
Connection via Ethernet to a PC realized
No USB stick in-
serted
No USB stick found
USB stick inserted
USB stick detected
