TOX EPW400 User Manual

Technical data
OM 100.EPW 400.202002.en 21
3.1.13 DMS signals
Force measuring (channel Y) via DMS force transducer. The input is selected in menu
'Configuration'.
Nominal force or nomi-
nal distance:
Adjustable in the menu
A/D converter:
16 bit = 65536 steps
Nominal load of reso-
lution:
65536 steps, 1 step (bit) = nominal load / 65536
Gain error:
± 0.5%
Max. sampling rate:
2000 Hz (0.5 ms)
Bridge voltage:
5 V
Characteristic value:
Adjustable via the menu
Adjustment value
The entry 'Nominal force' must not be changed without the agree-
ment of the manufacturer.
