Technical data
OM 100.EPW 400.202002.en 41
Pin Profibus
3 RXD/TXD-P
4 CNTR-P (RTS)
5 0 V
6 + 5 V
8 RXD/TXD-N
Note
The output voltage from pin 6 for termination with a terminating re-
sistor is + 5 V.
