TOX EPW400 User Manual

Technical data
OM 100.EPW 400.202002.en 29
Channel Y oil pressure sensor
Connection example: ZDO
15-pin D-sub con-
nector, analog I/O
Channel X distance transducer
Connection example of distance potentiometer (ZWW 10 V supply voltage)
15-pin D-sub connector,
analog I/O
Connection example of distance transducer (ZKW 24 V supply voltage)
15-pin D-sub con-
nector, analog I/O
