Operating the device
62 OM 100.EPW400.202002.en
In 'Teach' mode, the measured curves are plotted and the envelope limits are gener-
ated. This results in an upper and a lower envelope.
In mode 'Teach new', the existing envelopes are cancelled and the envelope end is
built again based on the following measurements.
A change from mode 'Evaluation' to mode 'Teach' is always possible for teaching fur-
ther curves.
If in mode 'Evaluation' a curve violates the upper or the lower envelope, a button ap-
pears in menu 'Envelope' where a teach-in of this curve can be added to the envelope.
