Operating the device
64 OM 100.EPW400.202002.en
Tap on 'Begin Y' to set the value to '0'.
Change the mode to 'Teach new', or to 'Teach' if previously taught curves are to
be retained.
Go to the 'Main menu'.
Draw the required number of curves (measure).
Go to the 'Envelope' menu again.
Using SX and/or SY, move the upper / lower envelope horizontally / vertically by
entering the desired value.
The upper / lower envelope can be limited or expanded horizontally using Begin
X / End X and limited or expanded vertically using Begin Y / End Y.
Go to 'Evaluate' mode.
Go to the 'Main menu'.
The curves will now be recorded, and evaluated on the basis of the envelope and
any windows that have been set.
