turck TBEN-L Series User Manual

105
2017/06
12.4.3 TBEN-Lx-8DIP-8DOP – Diagnostic Data Mapping
A Slot in configuration toll (e.g. Siemens HW Config)
Station diagnostics (slot 0 A)
PROFINET diagnostics
Diagnostics Channel Error code Chan-
nel
Undervoltage
V1 0.0 - 0x0002 0
V2 0.1 - 0x0002 1
I/O-diagnostics (slot 1 A)
PROFINET diagnostics
Diagnostics Channel Connector/
pin
Error code Chan-
nel
Overcurrent power supply at connector (SCSx) Overcurrent VAUX
SCS0 E1.0 C0 0x001A 0
E1.1
SCS1 E1.2 C1 0x001A 1
E1.3
SCS2 E1.4 C2 0x001A 2
E1.5
SCS3 E1.6 C3 0x001A 3
E1.7
SCS4 E1.8 C4 0x001A 4
E1.9
SCS5 E1.10 C5 0x001A 5
E1.11
SCS6 E1.12 C6 0x001A 6
E1.13
SCS7 E1.14 C7 0x001A 7
E1.15
Overcurrent at output (SCOx) Overcurrent
SCO8 A1.0 C4P4 0x0001 0
SCO9 A1.1 C4P2 0x0001 1
SCO10 A1.2 C5P4 0x0001 2
SCO11 A1.3 C5P2 0x0001 3
SCO12 A1.4 C6P4 0x0001 4
SCO13 A1.5 C6P2 0x0001 5
SCO14 A1.6 C7P4 0x0001 6
SCO15 A1.7 C7P2 0x0001 7
