8.5 TBEN-Lx-8DIP-8DOP
The station offers eight digital inputs for 3-wire PNP-sensors and eight digital PNP outputs for DC
actuators.
8.5.1 Technical Data
8.5.2 Wiring Diagram
 Connecting the Devices to Ethernet, page 27
 Connect Power Supply, page 28
Connecting Digital Sensors and Actuators, page 30
power supply
Nominal value 24 V DC from operating voltage
Permissible range 18 … 30 V DC
Operating current < 150 mA
Sensor/actuator supply V
AUX1
/V
AUX2
supply of connectors
C0 - C3 from V1
C4 - C7 from V2
120 mA per connector, short-circuit proof
Digital inputs
Number of channels 8
Input type PNP
Switching threshold EN 61131-2 type 3, PNP
Low level signal voltage < 5 V
High level signal voltage > 11 V
Low level signal current < 1.5 mA
High level signal current > 2 mA
Switch-on delay 2.5 ms
Type of input diagnosis channel diagnostics
Digital outputs
Number of channels 8
Output type PNP
Output voltage 24 VDC from potential group
Load type ohmic, inductive, lamp load
Simultaneity factor 0.56 for entire module,
total current max. 9 A per module
Type of output diagnostics channel diagnosis
Potential isolation galvanic isolation to the field bus
