21
2017/06
Default Setting of the Device
The default-settings are as follows:
IP address 192.168.1.254
Subnet mask 255.255.255.0
Default gateway 192.168.1.1
5.2.7 Factory Reset (F_Reset), Switch Position "900"
F_Reset (Reset to factory setting)
Switch position: 900
This mode sets all device-settings back to the default values and deletes all data in the device's inter-
nal flash.
5.2.8 Functional Difference: Switch Position "000" and "900"
NOTE
The devices can be reset by the user to these default settings at any time.
To reset the module, set the three coding-switches on the gateway to "000" followed by a
voltage reset.
ATTENTION!
Protective cover opened
Protection class IP65/IP67/IP69K not guaranteed
Screw the protective cover over the switches firmly
Check if seal of the protective cover is correctly placed
NOTE
Setting 900 is no operation mode! Please set the device to another mode after having
reset the IP address to the default values.
ATTENTION!
Protective cover opened
Protection class IP65/IP67/IP69K not guaranteed
Screw the protective cover over the switches firmly
Check if seal of the protective cover is correctly placed
Reset of...
Switch position
000 900
IP address, subnet mask, gateway
Parameters –
PROFINET device name –
