61
2017/06
10.5.5 Meaning of the Register Bits
10.6 Register 0x100C: Station Status
This register contains a general module status.
Name Meaning
I/O data
DIx DI = digital input
DOx DO = digital output
Cx C = connector
Px P = pin
Diagnostics
DiagWarn see Register 0x100C: Station Status, page 61
V
1
V
2
COM
CFG
FCE
I/O Diag Group diagnostics of I/Os
SCSx Short-circuit at the supply voltage for the respective connector.
SCOx Overcurrent at the respective output
Parameters See "parameters"-section for the respective module type in chapter 8.
Bit Name Description
Device
15 – -
14 FCE The Force Mode is activated, which means, the actual output
values may no match the ones defined and sent by the field
bus.
13 – -
12 – -
Module bus
11 CFG Configuration error
10 COM Internal communication disturbed
Voltage errors
9V
1
System power supply too low (< 18 V DC).
8– -
7V
2
V2 too low (< 18 V DC).
6– -
5– -
4 – -
