11.7.2 Gateway Class (VSC 100)
This class contains all information concerning the whole module not the different
I/O channels.
Class Instance
Object Instance 1
NOTE
Please refer to section Class Instance of the VSCs, page 90 for the description of the class
instance for the VSC.
Attr. No.
dec.
(hex.)
Attribute name Get/
Set
Type Description
100
(0x64)
Max object attri-
bute
G USINT Contains the number of the last object
attribute to be implemented.
101
(0x65)
Hardware revision G STRUCT Contains the hardware revision number of
the module (USINT Maj./USINT Min.)
102
(0x66)
Firmware revision G STRUCT Contains the revision number of the boot
firmware (Maj./Min.).
103
(0x67)
Service tool ident
number
G UDINT Contains the BOOT ID number that serves
as an identification number for the DTM.
104
(0x68)
Hardware
Info
G STRUCT Contains module hardware information
(UINT):
– count (number of the following entries)
– CLOCK FREQUENCY (kHz)
– MAIN FLASH (in kB)
– MAIN FLASH SPEED (ns)
– SECOND FLASH (kB)
– RAM (kB),
– RAM SPEED (ns),
– RAM data WIDTH (bit),
– SERIAL EEPRPOM (kbit)
– RTC SUPPORT (in #)
– AUTO SERVICE BSL SUPPORT (BOOL)
– HDW SYSTEM
