11.7 VSC-Vendor Specific Classes
In addition to supporting the above named CIP Standard Classes, the TBEN-L stations support the
vendor specific classes described in the following.
11.7.1 Class Instance of the VSCs
The general VSC - class instance attributes are defined as follows.
Class Code
dec.
(hex.)
Name Description
100 (0x64) Gateway Class, page 91 Contains data and settings concerning the
field bus-specific part of the TBEN-L stations.
102 (0x66) Process Data Class, page 93 contains the process data
117 (0x75) Digital Versatile Module Class,
page 95 Describes the I/O channels
126 (0x1A) Miscellaneous Parameters Class, page 97 Describes the EtherNet/IP™-Port properties
NOTE
The class instance attributes are the same for each Vendor Specific Class.
The class-specific Object Instances and the corresponding attributes are explained in the
paragraphs for the different VSC.
Attr. No.
dec.
(hex.)
Attribute name Get/
Set
Type Description
100
(0x64)
Class revision G UINT Contains the revision number of the class
(maj. rel. *1000 + min. rel.).
101
(0x65)
Max. instance G USINT Contains the number of the highest
instance of an object created on this level
in the class hierarchy.
102
(0x66)
# of instances G USINT Contains the number of Object Instances
created in this class.
103
(0x67)
Max. class attribute G USINT Contains the number of the last class attri-
bute to be implemented.
