10.5.4 TBEN-Lx-16DXP/TBEN-L4-16DXN
 Meaning of the Register Bits, page 61.
Register Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
Packed input data
0x0000
Inputs
Byte 0 DI7
C3P2
DI6
C3P4
DI5
C2P2
DI4
C2P4
DI3
C1P2
DI2
C1P4
DI1
C0P2
DI0
C0P4
Byte 1 DI15
C7P2
DI14
C7P4
DI13
C6P2
DI12
C6P4
DI11
C5P2
DI10
C5P4
DI9
C4P2
DI8
C4P4
0x0001
Status word
Byte 0
V
2
–-----
Diag
Warn
Byte 1 – FCE – - CFG COM V
1
–
0x0002
group diag-
nostics
Byte 0–------I/O Diag
Byte 1
–-------
Inputs
0x8000 Byte 0 DI7
C3P2
DI6
C3P4
DI5
C2P2
DI4
C2P4
DI3
C1P2
DI2
C1P4
DI1
C0P2
DI0
C0P4
Byte 1 DI15
C7P2
DI14
C7P4
DI13
C6P2
DI12
C6P4
DI11
C5P2
DI10
C5P4
DI9
C4P2
DI8
C4P4
Packed output data
0x0800 DO7
C3P2
DO6
C3P4
DO5
C2P2
DO4
C2P4
DO3
C1P2
DO2
C1P4
DO1
C0P2
DO0
C0P4
DO15
C7P2
DO14
C7P4
DO13
C6P2
DO12
C6P4
DO11
C5P2
DO10
C5P4
DO9
C4P2
DO8
C4P4
Outputs
0x9000 Byte 0 DO7
C3P2
DO6
C3P4
DO5
C2P2
DO4
C2P4
DO3
C1P2
DO2
C1P4
DO1
C0P2
DO0
C0P4
Byte 1 DO15
C7P2
DO14
C7P4
DO13
C6P2
DO12
C6P4
DO11
C5P2
DO10
C5P4
DO9
C4P2
DO8
C4P4
Diagnostics
0xA000 Byte 0 SCS7 SCS6 SCS5 SCS4 SCS3 SCS2 SCS1 SCS0
Byte 1 SCO7 SCO6 SCO5 SCO4 SCO3 SCO2 SCO1 SCO0
0xA001 Byte 0 SCO15 SCO14 SCO13 SCO12 SCO11 SCO10 SCO9 SCO8
Byte 1–-------
Parameters
0xB000 reserved
0xB001 Byte 0 Inv. DI7 Inv. DI6 Inv. DI5 Inv. DI4 Inv. DI3 Inv. DI2 Inv. DI1 Inv. DI0
Byte 1 Inv. DI15 Inv. DI14 Inv. DI13 Inv. DI12 Inv. DI11 Inv. DI10 Inv. DI9 Inv. DI8
0xB002 Byte 0 SRO7 SRO6 SRO5 SRO4 SRO3 SRO2 SRO1 SRO0
Byte 1 SRO15 SRO14 SRO13 SRO12 SRO11 SRO10 SRO9 SRO8
0xB003 Byte 0 EN DO7 EN DO6 EN DO5 EN DO4 EN DO3 EN DO2 EN DO1 EN DO0
Byte 1 EN DO15 EN DO14 EN DO13 EN DO12 EN DO11 EN DO10 EN DO9 EN DO8
0xB004 Byte 0 reserved
Byte 1 Pulse stretching input 0
0xB005 Byte 0 Pulse stretching input 1
Byte 1 Pulse stretching input 2

Byte 0

Byte 1
0xB00B Byte 0 Pulse stretching input 13
Byte 1 Pulse stretching input 14
0xB00C Byte 0 Pulse stretching input 15
Byte 1 reserved
