turck TBEN-L Series User Manual

43
2017/06
8.6.2 Wiring Diagram
 Connecting the Devices to Ethernet, page 27
 Connect Power Supply, page 28
Connecting Digital Sensors and Actuators, page 30
8.6.3 Parameters for I/O Channels
Further information about parameters can be found in the fieldbus specific chapters.
 EtherNet/IP™: Digital Versatile Module Class (VSC117), page 95 ff.
 Modbus TCP: Register Mapping of the TBEN-L Devices, page 57 ff.
 PROFINET: Parameters, page 107
8.6.4 Diagnostic Messages
Further information about the diagnostic data mapping can be found in the fieldbus specific chap-
ters.
 Modbus TCP: Register Mapping of the TBEN-L Devices, page 57 ff.
 EtherNet/IP™: Digital Versatile Module Class (VSC117), page 95 ff.
 PROFINET: PROFINET-diagnostics, page 103
Parameter name Value Description
Digital input
Invert digital input (Inv. DIx)
0 = no
1 = yes The digital input signal is inverted.
Pulse stretching
input
0 - 255 The input signal is stretched to a time between 10
to 2550 ms.
Default setting:
0 = pulse stretching deactivated
(standard pulse = 2,5 ms)
Example:
10 = pulse of 100 ms
Manual output reset
at overcurrent (SROx)
0 = no The output switches on automatically after an
overload.
1 = yes The output is manually switched-off and on again.
Activate output
(EN DOx)
0 = no
1 = yes
Diagnostics Description
SCSx Short-circuit at the supply voltage for the respective connector.
SCOx Overcurrent at the respective output
