turck TBEN-L Series User Manual

Connecting
Hans Turck GmbH & Co. KG | T +49 208 4952-0 | F +49 208 4952-264 | more@turck.com | www.turck.com
30
7.3 Connecting Digital Sensors and Actuators
The device has eight 5-pin M12 connectors for connecting digital sensors and actuators. The maxi-
mum tightening torque is 0.8 Nm.
7.3.1 Inputs
 Connect the digital sensors to the device according to the pin assignment shown below.
Fig. 12: M12 connector for connecting digital sensors and actuators
TBEN-Lx-16DIP/TBEN-L4-16DIN
TBEN-Lx-8DIP-8DOP
4
1
3
2
5
v
1 = V
aux
1
2 = Signal In
3 = GND V1
4 = Signal In
5 = FE
C0...C7
5 FE
4 BK
1 BN +
3 BU –
3 BU –
2 WH
v
C0...C7
4
1
3
2
5
v
1 = V
aux
1
2 = Signal In
3 = GND V1
4 = Signal In
5 = FE
C0...C3
5 FE
4 BK
1 BN +
3 BU –
3 BU –
2 WH
v
C0...C3
